LC38MINI-DA-300-1050-SR
38 W DALI-2 dimmable LED driver for independent use
- 300 mA – 1050 mA adjustable current output
- Product number: 5900000
- Dimensions: 146,5 x 44 x 30 mm
- LED Driver family: MINI
- Main features: DALI, Amplitude, PanelReady
38 W DALI-2 dimmable LED driver for independent use
| Output | Adjustable current |
|---|---|
| Load protection | SELV60 |
| Max output power (W) | 38 |
| Efficiency up to (%) | 90 |
| Power factor at full load | 0.95 |
| Min | Max | ||
|---|---|---|---|
| Iout | 300 | 1050 | |
| Uout | 10–36 |
| Voltage range (VAC) | 198–264 |
|---|---|
| DC input characteristics | Approved for emergency lighting applications |
| DC range (V) | 176-275 |
| Max temperature at tc point (°C) | 85 |
| Ambient temperature range | –25 °C .. +45 °C |
| IP Rating | IP20 |
| Lifetime up to (h) | 100000 |
| Independent usage | ✓ |
| Luminaire class I | ✓ |
| Luminaire class II | ✓ |
| Luminaire class III | ✓ |
| Control | DALI-2 |
|---|---|
| Dimming range | 1% – 100% |
| Dimming method | Amplitude dimming |
| Complies with IEEE 1789-2015 | ✓ |
|---|---|
| Integrated strain relief | ✓ |
| Order code | Description |
|---|---|
| 5900000 | LC38MINI-DA-300-1050-SR 50 |
