Linear 20 mm LED Module
- Product number: 5173
- Dimensions: 279.5 x 19.8 x 6 mm
- Typical lumens (4000K @Tp): 2270
- Typical forward voltage (4000K @Tp) [v]: 24.3
- Typical efficacy (4000K @Tp) [lm/W]: 188
- LED Module family: Linear LX20
Linear 20 mm LED Module
- Product number: 5174
- Dimensions: 559.5 x 19.8 x 6 mm
- Typical lumens (4000K @Tp): 4560
- Typical forward voltage (4000K @Tp) [v]: 48.6
- Typical efficacy (4000K @Tp) [lm/W]: 188
- LED Module family: Linear LX20
Linear 20 mm LED Module
- Product number: 5175
- Dimensions: 1119.5 x 19.8 x 6 mm
- Typical lumens (4000K @Tp): 9120
- Typical forward voltage (4000K @Tp) [v]: 97.2
- Typical efficacy (4000K @Tp) [lm/W]: 188
- LED Module family: Linear LX20
Linear 20 mm LED Module
- Product number: 5176
- Dimensions: 1399.5 x 19.8 x 6 mm
- Typical lumens (4000K @Tp): 11410
- Typical forward voltage (4000K @Tp) [v]: 121.5
- Typical efficacy (4000K @Tp) [lm/W]: 188
- LED Module family: Linear LX20
- Typical lumens (4000K @Tp): 1610
- Typical efficacy (4000K @Tp) [lm/W]: 152
Tunable White Linear LED Module
- Dimensions: 279.8 x 23.8 x 6.2 mm
- Typical lumens (4000K @Tp): 1025
- Typical forward voltage (4000K @Tp) [v]: 14,9
- Typical efficacy (4000K @Tp) [lm/W]: 155
- LED Module family: Linear L-iC
- Main features: TunableWhite
- Tunable white
Tunable White Linear LED Module
- Dimensions: 559.8 x 23.8 x 6.2 mm
- Typical lumens (4000K @Tp): 2050
- Typical forward voltage (4000K @Tp) [v]: 27,4
- Typical efficacy (4000K @Tp) [lm/W]: 155
- LED Module family: Linear L-iC
- Main features: TunableWhite
- Tunable white
Linear LED Module
- Product number: 5153
- Dimensions: 139,8 x 23,8 x 6,2 mm
- Typical lumens (4000K @Tp): 645
- Typical forward voltage (4000K @Tp) [v]: 11.8
- Typical efficacy (4000K @Tp) [lm/W]: 156
- Replacing product: LS20-142
- LED Module family: Linear LS
- Typical lumens (4000K @Tp): 825
- Typical efficacy (4000K @Tp) [lm/W]: 148
Linear LED Module
- Product number: 5150
- Dimensions: 139,8 x 23,8 x 6,2 mm
- Typical lumens (4000K @Tp): 1290
- Typical forward voltage (4000K @Tp) [v]: 23.6
- Typical efficacy (4000K @Tp) [lm/W]: 156
- Replacing product: LS20-282
- LED Module family: Linear LS
- Typical lumens (4000K @Tp): 1100
- Typical efficacy (4000K @Tp) [lm/W]: 148
Linear LED Module
- Product number: 5152
- Dimensions: 279,8 x 23,8 x 6,2 mm
- Typical lumens (4000K @Tp): 2580
- Typical forward voltage (4000K @Tp) [v]: 47.2
- Typical efficacy (4000K @Tp) [lm/W]: 156
- Replacing product: LS20-562
- LED Module family: Linear LS
- Typical lumens (4000K @Tp): 1650
- Typical efficacy (4000K @Tp) [lm/W]: 148
Linear LED Module
- Product number: 5160
- Dimensions: 139,8 x 23,8 x 6,2 mm
- Typical lumens (4000K @Tp): 445
- Typical forward voltage (4000K @Tp) [v]: 8.75
- Typical efficacy (4000K @Tp) [lm/W]: 146
- LED Module family: Linear LP
Linear LED Module
- Product number: 5156
- Dimensions: 279,8 x 23,8 x 6,2 mm
- Typical lumens (4000K @Tp): 890
- Typical forward voltage (4000K @Tp) [v]: 17.5
- Typical efficacy (4000K @Tp) [lm/W]: 146
- LED Module family: Linear LP
- Typical lumens (4000K @Tp): 2200
- Typical efficacy (4000K @Tp) [lm/W]: 148
Linear LED Module
- Product number: 5155
- Dimensions: 559,8 x 23,8 x 6,2 mm
- Typical lumens (4000K @Tp): 1780
- Typical forward voltage (4000K @Tp) [v]: 34.9
- Typical efficacy (4000K @Tp) [lm/W]: 146
- LED Module family: Linear LP
- Typical lumens (4000K @Tp): 2655
- Typical efficacy (4000K @Tp) [lm/W]: 158
- Typical lumens (4000K @Tp): 1610
- Typical efficacy (4000K @Tp) [lm/W]: 152
- Typical lumens (4000K @Tp): 1515
- Typical efficacy (4000K @Tp) [lm/W]: 143
